使用kubeadm创建一个K8s 1.10的Cluster

使用kubeadm创建一个K8s 1.10的Cluster

我们有很多种方式在很多种环境下安装配置Kubernetes的cluster(包含master和worker nodes),如 Picking the Right Solution所展示的这样。 本文中,Gemfield将演示如何使用kubeadm在Bare metal的Ubuntu操作系统中创建一个K8s的Cluster,版本为1.10。

注意:1.11已经发布,关于1.11的部署可以参考专栏文章:

Gemfield:使用kubeadm安装Kubernetes 1.11zhuanlan.zhihu.com图标

一,为每个node安装kubeadm

1,禁掉swap分区

gemfield@sl:~$ sudo swapoff -a

#要永久禁掉swap分区,打开如下文件注释掉swap那一行
gemfield@sl:~$ sudo vi /etc/fstab

这一步是为了让kubelet正常工作,否则会报错:

11月 25 16:52:38 sl kubelet[2856]: error: failed to run Kubelet: Running with swap on is not supported, please disable swap! or set --fail-swap-on
11月 25 16:52:38 sl systemd[1]: kubelet.service: Main process exited, code=exited, status=1/FAILURE
11月 25 16:52:38 sl systemd[1]: kubelet.service: Unit entered failed state.
11月 25 16:52:38 sl systemd[1]: kubelet.service: Failed with result 'exit-code'.


2,可以得到机器的MAC和product_uuid

gemfield@sl:~$ ip link
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN mode DEFAULT group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
2: enp8s0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP mode DEFAULT group default qlen 1000
    link/ether 60:eb:69:af:b2:76 brd ff:ff:ff:ff:ff:ff
3: wlp5s0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP mode DORMANT group default qlen 1000
    link/ether 5c:ac:4c:bf:6d:12 brd ff:ff:ff:ff:ff:ff
4: docker0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN mode DEFAULT group default
    link/ether 02:42:d2:2f:a7:0b brd ff:ff:ff:ff:ff:ff

gemfield@sl:~$ sudo cat /sys/class/dmi/id/product_uuid
20FD5881-4A7E-11CB-A0FC-C6E1CB03C2A6

确保Kubunetes能正确使用机器的网卡设备,在多网卡的环境下,有必要的时候你要设置路由。

另外,需要以下TCP端口:

#Master Node上
6443*,Kubernetes API server
2379-2380, etcd server client API
10250, Kubelet API
10251,kube-scheduler
10252,kube-controller-manager
10255,Read-only Kubelet API

#worker node上需要以下TCP端口:
10250,Kubelet API
10255,Read-only Kubelet API
30000-32767,NodePort Services**


3,安装Docker

在每台机器上安装docker,在今天(2018年4月27日)这个时刻,这些docker版本是验证过的:v1.12、 v1.11、v1.13和17.03。使用下面的命令来安装docker。

gemfield@sl:~$ sudo apt-get update
gemfield@sl:~$ sudo apt-get install -y docker.io

更多docker详情,请参考Gemfield专栏的前述文章


4,安装kubeadm、kubelet、kubectl

这3个包要在所有的机器上安装。

  • kubeadm:从零开始配置K8s cluster的tool。目前kubeadm整体还是beta状态,官方宣称的是在2018年结束之前变为General Availability (GA)状态。
  • kubelet: 集群的每个机器上都需要运行的组件,用来启动pods和containers。
  • kubectl: 用来和集群交互的命令行工具。

配置如下apt源

gemfield@sl:~$ cat /etc/apt/sources.list.d/kubernetes.list
deb http://apt.kubernetes.io/ kubernetes-xenial main

配置apt的proxy来翻墙

因为下载的package都在packages.cloud.google.com 下,你懂的。

gemfield@sl:~$ cat /etc/apt/apt.conf
Acquire::http::Proxy "http://gemfield.org:7030";
Acquire::https::Proxy "http://gemfield.org:7030";
gemfield@sl:~$

安装这个源的公钥

#配置代理,mmp你懂的
gemfield@edge:~$ export http_proxy=gemfield.org:7030
gemfield@edge:~$ export https_proxy=gemfield.org:7030

#安装
gemfield@sl:~$ curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add -

否则无法验证签名,会出现如下错误:

获取:3 https://packages.cloud.google.com/apt kubernetes-xenial InRelease [8,942 B]
错误:3 https://packages.cloud.google.com/apt kubernetes-xenial InRelease
  由于没有公钥,无法验证下列签名: NO_PUBKEY 3746C208A7317B0F
正在读取软件包列表... 完成
W: GPG 错误:https://packages.cloud.google.com/apt kubernetes-xenial InRelease: 由于没有公钥,无法验证下列签名: NO_PUBKEY 3746C208A7317B0F
E: 仓库 “http://apt.kubernetes.io kubernetes-xenial InRelease” 没有数字签名。
N: 无法安全地用该源进行更新,所以默认禁用该源。
N: 参见 apt-secure(8) 手册以了解仓库创建和用户配置方面的细节。

值得再次强调的是,这个代理不止在这里起作用,而且在下面运行kubeadm init的时候也需要。继续看吧。

运行apt update更新源

gemfield@gemfield:~$ sudo apt update

9,安装kubeadm, kubelet 和 kubectl

gemfield@gemfield:~$ sudo apt install -y kubelet kubeadm kubectl
正在读取软件包列表... 完成
正在分析软件包的依赖关系树
正在读取状态信息... 完成
将会同时安装下列软件:
  ebtables kubernetes-cni
下列【新】软件包将被安装:
  ebtables kubeadm kubectl kubelet kubernetes-cni
升级了 0 个软件包,新安装了 5 个软件包,要卸载 0 个软件包,有 0 个软件包未被升级。
需要下载 51.5 MB/51.6 MB 的归档。
解压缩后会消耗 369 MB 的额外空间。
......

master node 就是运行了control plane组件的机器, 包括etcd (the cluster database)和 API server (也就是kube-apiserver,让kubectl命令交互的)。也就是说,kubectlkube-apiserver 交互来进行集群的管理。 发出的命令将实际工作在master node上,这是因为kube-apiserver运行在master node上。而在worker nodes上,将只运行kubeletkube-proxy

二,初始化master node

1,使用kubeadm init 去初始化master node

kubeadm init的时候要先想好使用什么网络插件,gemfield选择的是Calico插件,所以init时候的命令就是(注意:确保--pod-network-cidr的值不要和宿主机的局域网网段冲突):

#In order for Network Policy to work correctly, you need to pass --pod-network-cidr=172.16.0.0/16 to kubeadm init
kubeadm init --pod-network-cidr=172.16.0.0/16 --apiserver-advertise-address=192.168.1.118

这一步首先要配置好代理(export http_proxy=gemfield.org:17030),否则会报getsockopt: connection timed out错误:

root@gemfield:~# kubeadm init --pod-network-cidr=172.16.0.0/16 --apiserver-advertise-address=192.168.1.118
unable to get URL "https://dl.k8s.io/release/stable-1.10.txt": Get https://storage.googleapis.com/kubernetes-release/release/stable-1.10.txt: dial tcp 172.217.160.112:443: getsockopt: connection timed out

但是后面你又得去掉这个代理(unset http_proxy https_proxy,否则。。。继续看吧)。

2,设置好代理继续kubeadm init

#要用root账户去弄
root@gemfield:~# kubeadm init --pod-network-cidr=172.16.0.0/16 --apiserver-advertise-address=192.168.1.118
[init] Using Kubernetes version: v1.10.2
[init] Using Authorization modes: [Node RBAC]
[preflight] Running pre-flight checks.
......
Unfortunately, an error has occurred:
        timed out waiting for the condition

This error is likely caused by:
        - The kubelet is not running
        - The kubelet is unhealthy due to a misconfiguration of the node in some way (required cgroups disabled)
        - Either there is no internet connection, or imagePullPolicy is set to "Never",
          so the kubelet cannot pull or find the following control plane images:
                - k8s.gcr.io/kube-apiserver-amd64:v1.10.2
                - k8s.gcr.io/kube-controller-manager-amd64:v1.10.2
                - k8s.gcr.io/kube-scheduler-amd64:v1.10.2
                - k8s.gcr.io/etcd-amd64:3.1.12 (only if no external etcd endpoints are configured)

If you are on a systemd-powered system, you can try to troubleshoot the error with the following commands:
        - 'systemctl status kubelet'
        - 'journalctl -xeu kubelet'
couldn't initialize a Kubernetes cluster

上面的错误一定是墙的问题了,哼!不信你手工执行:

root@gemfield:~# docker pull k8s.gcr.io/kube-apiserver-amd64:v1.10.2
Error response from daemon: Get https://k8s.gcr.io/v1/_ping: dial tcp 64.233.189.82:443: i/o timeout

所以,为了docker pull能够正常工作,gemfield需要设置docker server的proxy。

3,设置docker server代理

注意啊,有2种代理,一种是docker client的,一种是docker server的,不要搞混了。这里设置的是docker server的:

#为docker service创建一个systemd drop-in 目录
mkdir -p /etc/systemd/system/docker.service.d

#使用下面内容创建文件/etc/systemd/system/docker.service.d/http-proxy.conf
[Service]
Environment="HTTP_PROXY=http://gemfield.org:17030/"

#使用下面内容创建文件/etc/systemd/system/docker.service.d/https-proxy.conf
[Service]
Environment="HTTPS_PROXY=http://gemfield.org:17030/"

#写入改动
sudo systemctl daemon-reload

#重启docker服务
sudo systemctl restart docker

#验证配置已经生效
root@gemfield:~# systemctl show --property=Environment docker
Environment=HTTP_PROXY=http://gemfield.org:17030/ HTTPS_PROXY=http://gemfield.org:17030/

重新pull:

root@gemfield:~# docker pull k8s.gcr.io/kube-apiserver-amd64:v1.10.2
v1.10.2: Pulling from kube-apiserver-amd64
f70adabe43c0: Pull complete
aaa6c3636312: Pull complete
Digest: sha256:1ba863c8e9b9edc6d1329ebf966e4aa308ca31b42a937b4430caf65aa11bdd12
Status: Downloaded newer image for k8s.gcr.io/kube-apiserver-amd64:v1.10.2

好了吧。好了我们就继续kubeadm init。

4,设置好docker server proxy后再次kubeadm init

root@gemfield:~# kubeadm init --pod-network-cidr=172.16.0.0/16 --apiserver-advertise-address=192.168.1.118
[init] Using Kubernetes version: v1.10.2
[init] Using Authorization modes: [Node RBAC]
[preflight] Running pre-flight checks.
......
[init] This might take a minute or longer if the control plane images have to be pulled.
......
完蛋了!死在这里了

使用journalctl -xeu kubelet 命令查看下log:

gemfield@gemfield:~$ journalctl -xeu kubelet
......
4月 28 17:13:29 sl kubelet[28886]: W0428 17:13:29.441478   28886 cni.go:171] Unable to update cni config: No networks found in /etc/cni/net.d
4月 28 17:13:29 sl kubelet[28886]: E0428 17:13:29.442451   28886 kubelet.go:2125] Container runtime network not ready: NetworkReady=false reason:NetworkPlugin
4月 28 17:13:34 sl kubelet[28886]: W0428 17:13:34.444718   28886 cni.go:171] Unable to update cni config: No networks found in /etc/cni/net.d
4月 28 17:13:34 sl kubelet[28886]: E0428 17:13:34.445849   28886 kubelet.go:2125] Container runtime network not ready: NetworkReady=false reason:NetworkPlugin
......

程序一直在循环报这个错误:Unable to update cni config: No networks found in /etc/cni/net.d。这是为什么呢?这是因为前面设置了代理,导致kubelet访问API Server不通,所以需要关闭http proxy。

gemfield@sl:~$ unset http_proxy https_proxy
#或者下面这个更优雅的方法
gemfield@sl:~$ export no_proxy=192.168.1.118

5,关闭http proxy后再次kubeadm init

root@sl:~# kubeadm init --pod-network-cidr=172.16.0.0/16 --apiserver-advertise-address=192.168.1.118
[init] Using Kubernetes version: v1.10.2
[init] Using Authorization modes: [Node RBAC]
[preflight] Running pre-flight checks.
        [WARNING FileExisting-crictl]: crictl not found in system path
Suggestion: go get github.com/kubernetes-incubator/cri-tools/cmd/crictl
[preflight] Some fatal errors occurred:
        [ERROR Port-6443]: Port 6443 is in use
        [ERROR Port-10250]: Port 10250 is in use
        [ERROR Port-10251]: Port 10251 is in use
        [ERROR Port-10252]: Port 10252 is in use
        [ERROR FileAvailable--etc-kubernetes-manifests-kube-apiserver.yaml]: /etc/kubernetes/manifests/kube-apiserver.yaml already exists
        [ERROR FileAvailable--etc-kubernetes-manifests-kube-controller-manager.yaml]: /etc/kubernetes/manifests/kube-controller-manager.yaml already exists
        [ERROR FileAvailable--etc-kubernetes-manifests-kube-scheduler.yaml]: /etc/kubernetes/manifests/kube-scheduler.yaml already exists
        [ERROR FileAvailable--etc-kubernetes-manifests-etcd.yaml]: /etc/kubernetes/manifests/etcd.yaml already exists
        [ERROR Port-2379]: Port 2379 is in use
        [ERROR DirAvailable--var-lib-etcd]: /var/lib/etcd is not empty

这是因为前面已经执行过一次kubeadm init了(其实是好几次...)。这个时候需要加个参数来忽略到这些:--ignore-preflight-errors=all

6,忽略所有前置检查错误后kubeadm init

root@gemfield:~# kubeadm init --pod-network-cidr=172.16.0.0/16 --apiserver-advertise-address=192.168.1.118 --ignore-preflight-errors=all
[init] Using Kubernetes version: v1.10.2
[init] Using Authorization modes: [Node RBAC]
[preflight] Running pre-flight checks.
......
[addons] Applied essential addon: kube-dns
[addons] Applied essential addon: kube-proxy

Your Kubernetes master has initialized successfully!

To start using your cluster, you need to run the following as a regular user:

  mkdir -p $HOME/.kube
  sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
  sudo chown $(id -u):$(id -g) $HOME/.kube/config

You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
  https://kubernetes.io/docs/concepts/cluster-administration/addons/

You can now join any number of machines by running the following on each node
as root:

  kubeadm join 192.168.1.118:6443 --token 9frx62.qp99ri6ds8mo6p41 --discovery-token-ca-cert-hash sha256:a7cff4b98899bcc0a4d5d9eae41648a8f42d4e7334ae52a3ec17910b7e4869af

终于成功了。注意最后的这3段输入,分别是:为正常非root用户所做的配置;部署pod network;添加其它node到这个集群(注意token是保密的,不要泄露给别人)。下面会继续提到。

7,去掉kubenetes配置文件中的http_proxy:

这些ENV变量都是从当前的会话中继承过去的(前面的步骤为了翻墙), 把这些值删掉:

root@master:~# find /etc/kubernetes/ -type f -exec grep -n 17030 {} \+
/etc/kubernetes/manifests/kube-controller-manager.yaml:30:      value: http://localhost:17030
/etc/kubernetes/manifests/kube-controller-manager.yaml:32:      value: http://localhost:17030
/etc/kubernetes/manifests/kube-apiserver.yaml:45:      value: http://localhost:17030
/etc/kubernetes/manifests/kube-apiserver.yaml:47:      value: http://localhost:17030
/etc/kubernetes/manifests/kube-scheduler.yaml:21:      value: http://localhost:17030
/etc/kubernetes/manifests/kube-scheduler.yaml:23:      value: http://localhost:17030

然后重启kubelet service:

gemfield@master:~$ sudo systemctl restart kubelet.service

8,使用非root的正常用户执行以下配置

gemfield@sl:~$ mkdir -p $HOME/.kube
gemfield@sl:~$ sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
[sudo] gemfield 的密码:
gemfield@sl:~$ sudo chown $(id -u):$(id -g) $HOME/.kube/config

三,部署pod network

1,安装Calico pod network

注意修改官方的calico.yaml 中的CALICO_IPV4POOL_CIDR的值来避免和宿主机所在的局域网段冲突(gemfield就是把原始的192.168.0.0/16 修改成了172.16.0.0/16):

gemfield@sl:~$ kubectl apply -f https://docs.projectcalico.org/v3.1/getting-started/kubernetes/installation/hosted/kubeadm/1.7/calico.yaml
Unable to connect to the server: Access violation

这是因为当前的terminal的会话里设置了http_proxy和https_proxy,使得kubectl不能访问kube-apiserve。使用下面的命令来修复这个问题:

#kube-apiserve的IP为192.168.1.118
gemfield@sl:~$ export no_proxy=192.168.1.118

2,再次安装Calico pod network

gemfield@sl:~$ kubectl apply -f https://docs.projectcalico.org/v3.1/getting-started/kubernetes/installation/hosted/kubeadm/1.7/calico.yaml
configmap "calico-config" created
daemonset.extensions "calico-etcd" created
service "calico-etcd" created
daemonset.extensions "calico-node" created
deployment.extensions "calico-kube-controllers" created
clusterrolebinding.rbac.authorization.k8s.io "calico-cni-plugin" created
clusterrole.rbac.authorization.k8s.io "calico-cni-plugin" created
serviceaccount "calico-cni-plugin" created
clusterrolebinding.rbac.authorization.k8s.io "calico-kube-controllers" created
clusterrole.rbac.authorization.k8s.io "calico-kube-controllers" created
serviceaccount "calico-kube-controllers" created

3, 确保所有的pod此刻都是running

使用kubectl get pods --all-namespaces来查看。

gemfield@sl:~$ watch kubectl get pods --all-namespaces
#输出
NAMESPACE     NAME                                       READY     STATUS              RESTARTS   AGE
kube-system   calico-etcd-z4vwl                          1/1       Running             0          9m
kube-system   calico-kube-controllers-685755779f-tkssx   0/1       Pending             0          9m
kube-system   calico-node-2fw5b                          0/2       ContainerCreating   0          9m
kube-system   etcd-sl                                    1/1       Running             0          47m
kube-system   kube-apiserver-sl                          1/1       Running             0          47m
kube-system   kube-controller-manager-sl                 1/1       Running             0          47m
kube-system   kube-dns-86f4d74b45-psbkm                  0/3       Pending             0          46m
kube-system   kube-proxy-qsf27                           1/1       Running             0          46m
kube-system   kube-scheduler-sl                          1/1       Running             0          47m

就在这里看着,直到所有的状态都变成Running。Gemfield大约等了20分钟,可能是在pull image吧。

gemfield@sl:~$ watch kubectl get pods --all-namespaces
#输出
NAMESPACE     NAME                                       READY     STATUS    RESTARTS   AGE
kube-system   calico-etcd-z4vwl                          1/1       Running   0          21m
kube-system   calico-kube-controllers-685755779f-tkssx   1/1       Running   0          21m
kube-system   calico-node-2fw5b                          2/2       Running   0          21m
kube-system   etcd-sl                                    1/1       Running   0          59m
kube-system   kube-apiserver-sl                          1/1       Running   0          59m
kube-system   kube-controller-manager-sl                 1/1       Running   0          59m
kube-system   kube-dns-86f4d74b45-psbkm                  3/3       Running   1          59m
kube-system   kube-proxy-qsf27                           1/1       Running   0          59m
kube-system   kube-scheduler-sl                          1/1       Running   0          59m

4,确定你的集群里现在有node了

gemfield@sl:~$ kubectl get nodes -o wide
NAME      STATUS    ROLES     AGE       VERSION   EXTERNAL-IP   OS-IMAGE             KERNEL-VERSION      CONTAINER-RUNTIME
sl        Ready     master    1h        v1.10.1   <none>        Ubuntu 16.04.3 LTS   4.13.0-38-generic   docker://1.13.1

四,添加其它node

登陆到需要添加的node上,切换到root账户(注意:如果你在墙内,这个node也需要配置docker server的代理)。

#切换到root账户下
root@ai:~# kubeadm join 192.168.1.118:6443 --token 9frx62.qp99ri6ds8mo6p41 --discovery-token-ca-cert-hash sha256:a7cff4b98899bcc0a4d5d9eae41648a8f42d4e7334ae52a3ec17910b7e4869af
[preflight] Running pre-flight checks.
        [WARNING SystemVerification]: docker version is greater than the most recently validated version. Docker version: 17.12.0-ce. Max validated version: 17.03
        [WARNING FileExisting-crictl]: crictl not found in system path
Suggestion: go get github.com/kubernetes-incubator/cri-tools/cmd/crictl
[discovery] Trying to connect to API Server "192.168.1.118:6443"
[discovery] Created cluster-info discovery client, requesting info from "https://192.168.1.118:6443"
[discovery] Requesting info from "https://192.168.1.118:6443" again to validate TLS against the pinned public key
[discovery] Cluster info signature and contents are valid and TLS certificate validates against pinned roots, will use API Server "192.168.1.118:6443"
[discovery] Successfully established connection with API Server "192.168.1.118:6443"

This node has joined the cluster:
* Certificate signing request was sent to master and a response
  was received.
* The Kubelet was informed of the new secure connection details.

Run 'kubectl get nodes' on the master to see this node join the cluster.

编辑于 2018-08-10

文章被以下专栏收录
